Greasing Bonded Rubber Bushing: be lubricated. from the top working outward. – Use the Grease - N.052.150.00.- . – The required quantity of grease together for both sides should be approximately 1 cm -dimension a- as shown. • Half of the grease quantity (approximately 0.5 cm) must be applied per kidney-shaped area. – The grease quantity must be applied on the top using a com‐ mercially available brush. – The contact surfaces to the control arm must not come in con‐ tact with grease. – Install the control arm ⇒ “4.2 Lower Control Arm, Removing and Installing”, ♦ Vehicles with manual transmission, DSG transmission 0CW. ♦ Vehicles with DSG Transmission 0D9. Refer to |
