3
Technical Data
⇒ “3.1 Brakes Technical Data”, page 3
3.1
Brakes Technical Data
⇒ “3.1.1 Brake Master Cylinder and Brake Booster”, page 3
⇒ “3.1.2 Front Brakes”, page 3
⇒ “3.1.3 Rear Brakes”, page 5
3.1.1
Brake Master Cylinder and Brake Boos‐
ter
Brake master cylinder,
depending on the en‐
gine installed
Diameter in mm
23.81 or 25.4
Brake booster, depend‐
ing on the engine instal‐
led
Diameter in in‐
ches
10 or 11
3.1.2
Front Brakes
Front Brakes PC57 (15”)
Item PR Number
1ZE/1ZP
1
Brake caliper
PC57 (15”)
2
Brake pad,
thickness
mm
14
Brake pad, wear
limit without
back plate
mm
2
3
Brake rotor
diam‐
eter in
mm
288
Brake rotor,
thickness
mm
25
Brake rotor,
wear limit
mm
22
4
Brake caliper,
piston
diam‐
eter in
mm
57
