– Remove all wires from the transmission. the connector -arrow- from the Transmission Neutral Position Sensor - G701- . – Remove the starter. Refer to ⇒ Electrical Equipment; Rep. Gr. 27 ; Starter; Starter, Removing and Installing . – Remove the nuts -1- from both sides of the coupling rod -3-. bar -2-. – If equipped, remove the Left Front Level Control System Sen‐ sor - G78- from the lower control arm. Refer to ⇒ Suspension, Wheels, Steering; Rep. Gr. 43 ; Level Control System Sensor; Overview - Front Level Control System Sensor . – Remove the drive axle heat shield -arrows- (if equipped). Re‐ fer to ⇒ Suspension, Wheels, Steering; Rep. Gr. 40 ; Drive Axle; Drive Axle Heat Shield, Removing and Installing . – Remove the drive axles from the flange shafts and tie them up as high as possible. Be careful not to damage the surface pro‐ tection. Refer to ⇒ Suspension, Wheels, Steering; Rep. Gr. 40 ; Drive Axle; Drive Axle, Removing and Installing . |
