❑ The design depends on the vehicle equipment ⇒ “2.14.1 Door Sill Side Seat Trim, Removing and Installing, Except Power Seat”, page 345 . 9 - Seat Trim Panel ❑ Tunnel side ⇒ “2.13 Tunnel-Side Seat Trim, Removing and Installing”, page 344 10 - Seat Belt Latch ❑ Removing and installing. Refer to ⇒ “1.14 Front Seat Belt Latch, Removing and Installing”, page 120 2.5.2 Overview - Seat Pan, Power Note The illustration shows the driver side seat pan. The seat pan on the front passenger side is similar. 1 - Seat Cushion ❑ Seat Pan Cover and Padding, Removing and installing. Refer to ❑ Seat pan cover and cushion, separating. Refer to . 2 - Seat Pan ❑ 22 Nm bolts must be cleaned, for example, with a thread tap 4 - Screw ❑ 8 Nm 5 - Bracket ❑ For the sill-side seat trim panel ❑ Removing and instal‐ ling. Refer to Installing, Power Seat”, page 349 . |
