– Loosen the clips -2- for the door trim panel -1- out of the mounts using the Wedge Set - T10383- . The clip -3- was al‐ ready released. Note ♦ For 4-door vehicles, the left upper clip -arrow- is designed as a crash clip. When prying out the door trim panel, it is automatically released from the window shaft strip. ♦ A crash clip is not installed on 2-door vehicles. All door trim panel clips must be released as described. Caution If the door trim panel is pulled vertically upward out of the win‐ dow shaft strip, make sure that the door trim panel does not bump into the mirror cover trim and become damaged. – Remove the door trim panel -1- vertically from the window shaft strip. The crash clip -arrow- is automatically released on 4-door vehicles. – Depending on the vehicle equipment level, disconnect the connectors from the door trim panel -1-. |
