7 - Steering Wheel with Multifunction ❑ Equipment levels Wheel . 8 - Wiring Harness with Multifunction ❑ For Driver Airbag Igniter - N95- ⇒ “5.3 Airbag Connector, Replacing”, page 136 . ❑ Press in to secure in the pockets on the steering wheel. 9 - Driver Side Airbag ❑ With Driver Airbag Igniter - N95- WARNING Observe the safety pre‐ cautions for pyrotechni‐ cal components. Refer to . ❑ Removing and installing. Refer to ⇒ “5.2 Airbag Unit with Igniter, Removing and Installing”, page 132 10 - Screw ❑ Tightening specification. Refer to ⇒ Suspension, Wheels, Steering; Rep. Gr. 48 ; Steering Wheel; Overview - Steering Wheel . 5.2 Airbag Unit with Igniter, Removing and Installing Special tools and workshop equipment required mercially available Removing WARNING ♦ Observe the safety precautions for pyrotechnical compo‐ nents. Refer to ⇒ “1.2 Safety Precautions for Pyrotechnic Components”, . ♦ Observe the disposal regulations for pyrotechnical com‐ ponents. Refer to ⇒ “1.3 Airbag, Belt Tensioner and Battery Cut-Out Units, Storing, Transporting and Disposing (Pyrotechnic Com‐ . – Position the steering wheel as far back and down as possible. ⇒ “1.11 Upper Steering Column Trim Panel, Removing and – Turn the steering wheel so the opening on the rear side of it faces upward. |
