⇒ “6.12.2 Luggage Compartment Side Trim Panel, Removing and Installing, Wagon”, page 291 . – Remove the outer rear belt end fitting. Refer to ⇒ “1.12 Rear Outer Belt End Fitting, Removing and Installing”, WARNING Electrostatic discharges can lead to unintended deployment of the airbag. Therefore the technician must discharge static elec‐ tricity from the body before separating the ignition and ground wiring. This is done, for example, by briefly touching the body or door striker. – Disconnect the wiring harness and unclip the connector -1-. |
