Caution Due to the lack of clearance between the front trim and the frame, set a stop depth of 5 mm. – Cut off the front trim using the Window Cutter - VAG1561A- and the Window Cutter - Saw Blade - 83mm - VAG1561/26- along the markings from the back toward the front. – Apply the markings with the distance -b- = 10 mm from the front edge and with the distance -c- = 10 mm from the rear edge outward. |
