DQ-250 6F 02E DTC Fault Code De‐ scription Monitor Strat‐ egy Descrip‐ tion Malfunction Criteria Threshold Value Secondary Pa‐ rameters with Enable Condi‐ tions Monitor‐ ing Time Length Frequen‐ cy of checks, MIL Illum • plausibility check of se‐ lector lever • selector lever posi‐ tion is not equal to negation of the inverse selector lever posi‐ tion OR • selector lever posi‐ tion equals initializa‐ tion value OR • selector lever posi‐ tion equals error value OR • selector lever posi‐ tion is equal to negation of the inverse selector lever posi‐ tion but no valid posi‐ tion • selector lever posi‐ tion = Posi‐ tion 1 or Position 2 or Position 3 or Posi‐ tion 4 or Position L • no bus off er‐ ror • no error fail‐ ure of all CAN mes‐ sages • no failure of selector lev‐ er CAN mes‐ sages • time after Reset > 1100 ms • terminal 15 voltage > 9 V for more than 1100 ms • 1000 ms • question and answer diagnosis • failure of question and an‐ swer diag‐ nosis
• 1500 ms P0919 Gear Shift Po‐ sition Control Error • evaluation the error signal of se‐ lector lever CAN mes‐ sage • error flag of not de‐ terminable selector lever posi‐ tion is set
• no failure of selector lev‐ er CAN mes‐ sages • terminal 15 voltage > 4 V for more than 500 ms • battery volt‐ age > 9 V for more than 500 ms • engine speed > 500 rpm • 20 ms • 2 driv‐ ing cy‐ cles GTI 2014 ➤ Generic Scan Tool - Edition 04.2015 3. Diagnosis and Testing 449 |
