- Place foam shims contained in repair set between window
regulator motor and carrier assembly.
- Install motor for window regulator.
- Tighten bolts to 3.5 Nm.
Vehicles with mechanical window regulators
- Connect transfer element for cable reel - 1 - .
- Insert new seals - 2 - .
- Connect crank mechanism - 2 - . If necessary, align
transfer element for cable reel and crank mechanism. To
do so, rotate transfer element as far until transfer element
and crank mechanism have correct position to each other.
- Tighten bolts to - 1 - to 3.5 Nm.
Continued for all vehicles
- Installing carrier assembly with window regulator
64-2,
Carrier assembly, removing and installing
.
- Slide door window into clamping brackets without
excessive force and align to rear window guide.
- Tighten bolts for clamping brackets to 10 Nm.
Door windows
13/2/2005
