34-26
Functional check
Gear shift lever must rest in 3rd/4th gear gate with transmission in neutral.
- Operate clutch.
- Select all gears several times. Pay particular attention to operation of reverse gear lock.
Should a gear fail to engage smoothly after
- Carefully guide gear shift lever in neutral to left into gate for 1st/2nd gear.
If this cannot be accomplished: Selector shaft must move downward (arrow - To check if shift mechanism is correctly adjusted, have second technician attempt to - Adjust selector mechanism,
Page 34-22 Gear selector mechanism, servicing |
