91-23







Anti-theft security code, inputting





   The security code is "fixed", meaning the radio is

programmed by the radio manufacturer to accept
only one code. This code must be input during
the new vehicle delivery inspection, into newly
installed or existing units that have been
removed and reinstalled.



   Prerequisites:





 Obtain security code, either from code card or

from customer.





 Radio power supply fuse OK (according to

wiring diagram)



   Inputting code / cancelling electronic lock-up





-  Switch on radio





 "SAFE" appears in radio display, followed by

"1000" approximately 3 seconds later.





-  Input the security code found on the radio card

using the station preset buttons on the radio.
Button "1" corresponds to the first number in the
security code, "2" the second and so on. Press
the applicable button repeatedly until the desired
number appears in the display (E.g.: press
button "1" three times if the first number in the
code is 3).





-  When the entire code has been input and

appears on the display, press the right side of
the "Seek" button ("

") for longer than 2

seconds until an audible signal is heard.

Radio, Premium V and Premium V - Monsoon

13/2/2005

91-24





   Incorrect code number



   If an incorrect code is entered, "SAFE" will

appear in the display (first blinking and then
continuous) and the radio will not function.
The entire coding procedure can only be
repeated one more time immediately (the
number of attempts is displayed).



   If during the second attempt an incorrect

code is entered, the radio will lock-up for
approximately one hour. Leave key in
ignition, radio switched on for 1 hour and
attempt coding again when the number of
attempts on display goes out (ensure proper
code is available).



   Cycle: 2 attempts - 1 hour lock-up still

applies.

Radio, Premium V and Premium V - Monsoon

13/2/2005

91-25







Radio, "Premium VI" &
"Premium VI -
Monsoon"





General information







Radio system "Premium VI" and
"Premium VI - Monsoon" was
installed as a running change during
m.y. 2002. The system is
immediately identifiable by it's
"Double DIN" format.





"Premium VI radios are called
"Premium CD" in the owner's
literature.

     The radio system consists of an

integrated receiver/CD Player/tape
head unit and speakers located in
the front and rear doors.

A 168 mm low-range/bass speaker
is located in the lower portion of
each front and rear door.

High-range speakers (domed
tweeters) are integrated into the
forward window trim on both front
doors. Tweeters are integrated into
the rear door handle trim next to the
power window switches.

The optional "Premium VI -
Monsoon" system consists of the
"Premium VI" receiver/tape unit
supplemented by a separate high
power amplifier mounted in the
luggage compartment



page 91-

36

 .

High power handling speakers
specifically designed for the
"Monsoon" system are located in the
front and rear doors.

The system uses an amplified roof
mounted antenna



Page 91-47

 .

Radio, Premium VI and Premium VI - Monsoon

13/2/2005

The optional, luggage compartment
mounted CD Changer wiring and
mounting is pre-installed in
production



Page 91-58

 .

Radio, Premium VI and Premium VI - Monsoon

13/2/2005
