01-128
Fuel gauge, checking
If the fuel gauge displays the contents of the fuel tanks as being too high or too low, the fuel gauge
First perform the following procedures:
- Perform Output Diagnostic Test Mode (DTM) for instrument cluster
Page 01-86 .
If Output Diagnostic Test Mode (DTM) does not recognize a malfunction, check function of
- Check resistance value of sender for fuel gauge in read measuring value block, display group
Page 01-104 .
If Read Measuring Value Block does not indicate a short or open circuit in the wiring or the fuel
Page 01-129 . Instrument cluster m.y. 2000 through m.y. 2001, On Board Diagnostic (OBD) 13/2/2005 |
