of adapter cables required -1- and -3- and the connecting wire

-2-.
– To determine the length of connecting wire required, subtract

60 cm from the measured total length of aerial connecting wire

-2-.

– Procure the required adapter cables -1- and -3- and connect‐

ing wire -2- at the calculated length as genuine parts from the

parts catalogue (ETKA).

– Cut off connectors of defective aerial wire.
The remainder of the defective aerial wire remains in the vehicle.
– Connect adapter cables -1- and -3- to equipment in vehicle.
– Route and secure connecting wire -2- parallel to the old aerial

wire.

Note

Do not kink or excessively bend aerial wires! The bending radius

must not be below 50 mm.

– Connect connecting wire to adapter cables.
– Perform a functional check.
