Welding in

– Weld roof in front and rear window apertures, RP spot weld

seam.

Passat 2011 ➤ , Passat Variant 2011 ➤

2. Renewing roof - vehicles with sliding/tilting sunroof

121

continuous weld seam.

Passat 2011 ➤ , Passat Variant 2011 ➤

122

roof and roof side member to fully seal bonded seam -1-.

– After painting, preserve roof cavities -arrow- with corrosion-

preventive wax -AKR 321 M15 4- .

Passat 2011 ➤ , Passat Variant 2011 ➤

2. Renewing roof - vehicles with sliding/tilting sunroof

123

3

Renewing roof (Variant)

WARNING

Observe safety notes!

Safety notes ⇒ General Information; Body Repairs, General Body

Repairs ; Safety notes

1 - Roof
2 - Laser solder seam
3 - Bonded areas

Passat 2011 ➤ , Passat Variant 2011 ➤

124
