SEALING WINDOWS AND SCREENS

66

66 - 2

INSIDE WIPERS

DISMOUNTING
Dismount:

- opening handle
- window regulator crank
- door opening mechanism
- door blocking button
- panel attachment screws

Detach the  panel.
Remove the inside wiper.

REMOUNTING
Perform in the reverse order the dismounting operations.

SEALING WINDOWS AND SCREENS

66

66 - 3

DISMOUNTING
Lower the window  in the  minimum position.
Dismount the outside wiper (1),  by

detaching it from the clips (2).

REMOUNTING
Perform in the reverse order the

dismounting operations.

OUTSIDE WIPERS

71

INTRENAL BODY TRIM

72 - 1

1. Front door threshold covering
2. Rear door threshold covering
3. Upper front pillar covering
4. Middle pillar lower covering
5. Middle pillar covering
6. Rear passage covering
7. Rear side panel covering
8. Rear wheel passage covering

CARRIAGE BODY COVERINGS

71

INTRENAL BODY TRIM

72 - 2

DISMOUNTING
Dismount :

- the  attachment screw of front door

threshold covering on the front pillar;

- the screws (2) and plastic nuts (4);
- release the front door threshold covering.

REMOUNTING
Perform in the reverse order the dismounting

operations.

FRONT DOOR THRESHOLD COVERING
