Dacia SuperNova (engine E7J). Manual - part 35
E7J-A-2/60 ENGINE
17
IGNITION AND INJECTION
17 - 50
DIAGNOSING-CONFORMITY TEST
LIST OF PARAMETERS
5.
Water tem-
perature sen-
sor
Parameter: water
temperature
X=
Engine
temperature +/- 5
0
C
If further problems
arise, refer to the diag-
nosing of that parameter
Parameter: air temperature
Air tempera-
ture sensor
X=
Temperature
under engine hood
+/- 5
0
C
If further problems arise,
refer to the diagnosing of
that parameter
6.
Pressure sen-
sor
Parameter: collector
pressure
Parameter: atmospheric
pressure
If further problems arise,
refer to the diagnosing of
those parameters
X=
Atmospheric
pressure
X=
Atmospheric
pressure
7.
COMMAN D OF A CTUATO RS
8. Petrol pump Command: relay of petrol
pu
mp
Functioning of
petrol pump must
be heard
If further problems arise,
refer to the diagnosing of
that command
Command: low speed cool-
ing ventilator
Command: high speed cool-
ing ventilator
Functioning of
low speed ventila-
tor must be heard
Functioning of
high speed venti-
lator must be
heard
If further problems arise,
refer to the diagnosing of
that command
If further problems arise,
refer to the diagnosing of
that command
Cooling
ventilator
If further problems arise,
refer to the diagnosing
for lack of conformity to
idle mode adjustment
Put hand under the
engine to feel its
functioning
Command: idle mode adjust-
ment engine
Step-by-step
engine
If further problems
arise, refer to the diag-
nosing defects along the
draining valve circuit
Valve must be
functional
Command: Canister draining
valve
Canister
draining
valve
9.
10.
11.
If further problems
arise, refer to the diag-
nosing of the states of air
conditioning
Compressor must
couple
Command: AC must be op-
erated through the board
switch
Air condi-
tioning (AC)
12.
Command: Water tempera-
ture alert light indicator on
board
Water tem-
perature alert
light indica-
tor
13.
