89

ELECTRIC DIAGRAMS

89 - 36

ENGINE WIRING

E7J262

X412

03

WATER TEMPERATURE INJECTION SENSOR

COOLING MOTOR FAN AND AIR CONDITION

(for vehicle with air conditioning)

Position Section

Destination

A

0.35

42A

SIGNAL + WATER TEMPERATURE

B1

0.60

3JK

- WATER TEMPERATURE

B2

0.60

3C

SIGNAL + WATER TEMPERATURE SENSOR

Position

Section

Destination

1

3.0

49B

CONTROL  + ENGINE COOLING FAN  > COOL

ING FAN RESISTANCE

1

5.0

49B

CONTROL + COOLING

FAN

2

5.0

MAJ

MASS



   Wires functions in connectors and couplings

89

ELECTRIC DIAGRAMS

89 - 37

AIR TEMPERATURE INJECTION SENSOR

ENGINE COOLING FAN RESISTANCE

(for vehicles with air  conditioning)

ENGINE WIRING

E7J262

X412

03

Position

Section

Destination

1

0.60

3B

SIGNAL + AIR TEMPERATURE SENSOR

2

0.60

3JQ

MASS AIR TEMPERATURE SENSOR

Position

Section

Destination

1

3.0

  49L

CONTROL + LOW SPEED COOLING FAN RESISTANCE

2

3.0

  49B

CONTROL + COOLING

 FAN

Wires functions in connectors and couplings

89

ELECTRIC DIAGRAMS

89 - 38

CANISTER PURGING VALVE

ENGINE WIRING

E7J262

B41

02

CY13C

NO

      371

3NR

X

3BB

X

1

2

Position

Section

Destination

1

0.60

  3NR

+ INJECTORS > OUTLE

T ACTUATORS  RELAY

2

0.60

  3BB

CONTROL CANISTER PURGE VALVE



   Wires functions in connectors and couplings

89

ELECTRIC DIAGRAMS

89 - 39

NO

    597

S04

R

E 0 4

R

BP1 7

B

B2

B4

B1

3JN

3NR

B7

B5

B6

49B

B8

B3

B9

BP7

OR

R

S01

E 0 1

B

BP7

R

R

H5

H1

H4

H2

H3

G

A

R

3NA

AP2 9

3AC

BP1 7

X
X

D5

D1

D4

D2

D3

R

R

GR

R

3NR

BP1 7

3 GT

BP1 7

OR

R

Wires functions in connectors and couplings
