Dacia Solenza (engine E7J). Manual - part 148

82

ACCOUSTIC WARNING - ANTI STARTING

82 - 49

Diagnostic – General

THE PROCEDURE OF
KEYS  ASSIGNATION

IMPORTANT

 : if not all keys are available it

will be necessary to subsequently perform the
assignation procedure with all the keys.

Ente r  in  dialogue  with syste m “A nti-

starting”.

In

  menu  ”Control menu”,  “Specific

control”, validate line “SC028: Key program-
ming”.

Tester is displaying: “Take off the key from

anti-theft contact”.

Tester is displaying “Enter the after-sale

code”.

With contact set off, enter the after-sale se-

cret code (12 hexadecimal characters)  and vali-
date it.

Tester is displaying “Attention. Not pre-

sented keys will be  not active. Re -launch
the procedure in order to re-assign them”:
the programming is under way.

Tester is displaying: “Insert key in anti-

theft contact and set the contact on, then
validate”: set the contact on using a vehicle key
or a new key.

Tester is displaying: “No of programmed

keys  1” and “ take off the key from anti-
theft contact, then validate”.

Tester is proposing: “Do you wish to pro-

gram a new  key ?”.

In order to assign additional keys, set the con-

tact on few seconds using the vehicle’s others
keys that must be assigned (maximum four), then
validate.

Tester is displaying: “2, 3, 4 programmed

keys” and “ take off the key from anti-theft
contact”.

ATTENT ION: these ones must be the

vehicle’s old keys or new not coded keys.

Tester is displaying: “ Data entry in memory”,

Cockpit Central Unit is coded and the keys are
assigned.

This message will be displayed for few

seconds, then you may come out from the re-
assignation procedure

ATTENTION: the maximum admissible

interval between each operation is of 5 min-
utes otherwise the procedure is canceled.

Tester is displaying in this situation the

me ssa ge :  “Pe r for ming conditions not
ac c omplishe d”. T his me ssa ge   is  a lso
displayed in case of dialogue loss with the
Cockpit Central Unit or in case of battery
supplying cutting off.

SPECIAL SITUATIONS

If tester is displaying:

“Cockpit Central Unit is empty. Launch

the C ockpit Central Unit programming
procedure”, then the Cockpit Central Unit is
not used. It is impossible to assign keys to a
not coded Cockpit Central Unit.

“Per forming conditions not accom-

plished”, the entere d code is  not correct;
check and then start again the code entering
procedure.

If the key does correspond to the Cockpit

Central Unit of that vehicle, the tester is dis-
playing “Interrupted procedure: attention,
the keys assigned  to the vehicle  are the
ones that have been assigned before pro-
cedure  starting. The pr esented keys be-
fore procedure interruption are not any-
more empty and can be only assigned to
this vehicle”  assigned.

82

ACCOUSTIC WARNING - ANTI STARTING

82 - 50

Diagnostic – General

THE PROCEDURE OF KEYS’ ASSIGNATION

Enter in dialogue with the

system “Anti-starting”

Select menu

“ Control module” and

“Specific control”.

Validate line  “SC 028:

Key programming”.

Tester is displaying: “

take off the key from

anti-theft contact”

Tester is displaying Enter

The after-sale code”.

Enter the code  (12
hexadecimal  characters
with capitals) then validate it

A

The procedure must be performed
 only when contact is  set off.

If tester is displaying:

“Cockpit Central Unit is

empty Launch the Cockpit
Central Unit programming

procedure”.



Tester is displaying

   “ Performing   conditions

not accomplished ”.

Cockpit Central Unit is new.

It is impossible to assign the

keys   to a Cockpit Central

Unit not coded.

The entered code is wrong or

it s not correct.

 Check and re-enter the code.

82

ACCOUSTIC WARNING - ANTI STARTING

82 - 51

Diagnostic – General

Tester is displaying: “Attention.
The non presented  keys

 shall be not

active. Re-launch the procedure in
order to re-assign them”.

Tester is displaying: “ Insert

key in anti-theft contact, set

contact on, then validate”.

Insert a key in anti-theft con-
tact. The key must be new or

belonging to this vehicle.

This procedure is enabling the

decommissioning of one key in

case of its loss, for instance

Tester is displaying: 1 key

Programmed”, “Take off the
key from anti-theft contact,

then validate”.

Tester is displaying: “ Do you

wish to program another key?”

Insert another new key or
belonging to this vehicle in

the anti-theft contact.

Tester is displaying: “ 2,3,4 keys
programmed

” then “T

ake off  the

key from the anti-theft contact, then

validat

e”.

Tester is displaying: “ Data

entry in memory”.

The keys are assigned to the

vehicle. Check if  the  vehicle is

starting and if the doors get

blocked by means of all keys

If tester is displaying:

“Interrupted procedure: at-

tention, the vehicle’s as-

signed keys are those that

were assigned before the

procedure launching. The

keys presented before the

procedure interruption are

not anymore empty and can

be assigned only to this ve-

hicle”.

The vehicle may use

maximum 4 keys.

The key does not

correspond to the

UCH of  this vehicle

82

ACCOUSTIC WARNING - ANTI STARTING

82 - 52

Diagnostic – General

THE CODING OF THE INJECTION COMPUTER.

The injection computer is delivered not coded. Therefore, the anti-starting system code

memorizing will be necessary, when its mounting, in order to authorize the vehicle starting.

It is sufficient to set the contact on for few seconds, without starting the engine. Set the

contact off and the anti-starting function will be ensured after few seconds (anti-starting red
LED is blinking)

ATTENTION:

By means of this anti-starting system, the vehicle is keeping  its own anti-starting code  on  all

its lifetime. Furthermore, this system does not have a breakdown code. Therefore, it is forbidden
to perform tests with injection computers borrowed from warehouse that must be after that
returned. The code memorized by the injection computer can not be anymore erased.
