IGNITION AND  INJECTION

17

17 - 66

Diagnostic – Conformity checking

Sequence

Function

Parameter/Cont

rolled

state or action

Visualization

Diagnostic

and Observations

 Engine

ET035 : Low speed engine fan

PASSIVE

Fan

PR002 : Water temperature

Engine fan must

run when engine

water temperature

is exceeding 99°C In case of a problem

consult the ET035

13

ET036 : High speed engine fan

ACTIVE

(ET036) diagnostic

(if equipped with AC).

PR002 : Water temperature

Engine fan must run

when engine water

temperature  is

exceeding 102 ° C

RECOMMENDATIONS The values shown on this conformity checking are only as indication.

Performing conditions: Warm engine at idling and no consumers.

IGNITION AND  INJECTION

17

17 - 67

Diagnostic – Conformity checking

Sequence

Function

Parameter/Controlled state or action

Visualization

Diagnostic

and Observations

ET032 : Canister purging

ACTIVE

1

 Canister purging

X > 1.5 % and variable

Nothing to be

PR023 : RCO canister purging

 noticed

valve

2

Speed vehicle

PR018 : Vehicle speed

X = The speed red on In case of a problem

the speedometer

consult the PR018

 in Km/hour

 diagnostic

3

 Detonation

Vehicle in charge

In case of a problem

sensor

PR013 :  Detonation average

X is variable

consult the PR013

signal

and different of 0

diagnostic

PR015 : Anti-detonation

0° < X < 7° RAC

correction.

4

Downstream

PR010 : Oxygen sensor voltage

Do not take into

oxygen sensor

consideration

voltage at idling

Running in full charge

The sensor is

showing

enriched mixture,

Nothing to be

  X is increasing with a

noticed

 small responding time

At deceleration, after an

The sensor is showing

acceleration with the pedal

poor mixture,

fully pressed.

X is decreasing with

a small responding

time.

RECOMMENDATIONS

The values shown on this conformity checking are only as indication.
Performing conditions:  During a drive test

IGNITION AND  INJECTION

17

17 - 68

Diagnostic – Conformity checking

Sequence

Function

Parameter/Controlled state

Visualization

Diagnostic

or action

and Observations

 After memorizing the adaptation

5

Enriching

values

adaptation

PR030 : Enriching adaptation in

In case of a problem

operation

consult the PRO030

E7J

80 <X<  176

and PR031

diagnostic

PR031 : Enriching adaptation
idling
E7J

80 <X<  176

At 2500 RPM, after running

CO < 0.3 %

CO

2

> 13.5 %

6

Pollution

O

2

< 0.8 %

In case of a problem

emission

HC < 100 ppm

consult the

0.97 <

λ < 1.03

“Anti-pollution

At idling after stabilization

CO < 0.5 %

 technical note”

HC < 100 ppm
0.97 <

λ < 1.03

RECOMMENDATIONS The values shown on this conformity checking are only as indication.

Performing conditions:  During a drive test

IGNITION AND  INJECTION

17

17 - 69

Diagnostic – States interpretation

ET009

CLIMATE CONTROL REQUEST

RECOMMENDATIONS

 No failure must be present or memorized.

The injection computer is not noticing the air conditioning starting control.

Check the insulation and continuity on the line from pin 23 (climate control of type Info Power
Absorbed by compressor) or from pin 46 (climate control of type Logical connection) of the injection
computer.
Mend if necessary.



If the problem is persisting  consult the climate control diagnostic.

AFTER

Restart the conformity checking from the beginning.

REPARATION
