Dacia Solenza (engine E7J). Manual - part 1

01 - 1

CHARACTERISTICS

Engine – Clutch - Gearbox

01

VEHICLE TYPE

ENGINE

 TYPE

CYLINDER

CAPACITY

(cm

3

)

CLUTCH

TYPE

GEARBOX

TYPE

DACIA SOLENZA

E7J-262

 1390

180 CPO 3300

JH3 - 051

01 - 2

01

CHARACTERISTICS

Vehicle identification

MANUFACTURER PLATE

The manufacturer plate is located on the radiator front

crossbeam.

1. Homologation number
2. Model year code and carriage body manufacturer series.
3. Maximum technical admissible weight  of the loaded car
4. Total maximum admissible weight (of the assembly)
5. Maximum technical admissible weight on  front axle;
6. Maximum technical admissible weight on rear  axle.
7. Vehicle code
8. Trailer maximum authorized weight without braking system

....... Kg

....... Kg

....... Kg

....... Kg

1

3

8

7

2

6

5

4

Manufacturer plate

VIN identification number

 UNITL THE DATE OF 26.06.2003

01 - 3

01

CHARACTERISTICS

 Vehicle identification

VIN IDENTIF

ICATION NUMBER

 5   A   7   1   5    3    *     *     *     *     *     *     *

POSITION



CHARACTERS EXPLANATION

1 - 3

– manufacturer world identification,

UU1 – AUTOMOBILE DACIA SA. ROMANIA,

4

– vehicle  destination,

R – vehicle for persons transportation,

5

–  power train unit location,

5 – transversal  front engine and front drive,

6

–carriage body type,

A – Hatchback (two volumes sedan) – restyled I,

7

– payload location,

                                   7 – 5 places: 2 front places + 3  rear fix bench places,

8

– gearbox  type,

1 – gearbox with  5 + 1 steps,

9

– engine code and vehicle driving post location,

5 – spark ignition engine (cylinder capacity 1400 cm

3

),

E7J 262 EURO 2, left hand drive,

6 – spark ignition engine (cylinder capacity 1400 cm

3

),

E7J 262 EURO 3, left hand drive,

10

– year model code  - 3 - 2003,

11 - 17

– carriage body manufacturing number.

 Positionn  1    2   3    4   5   6   7   8   9   10   11   12   13   14   15   16   17

Code



U   U   1   R

VIN IDENTIF

ICATION NUMBER

 UNITL THE DATE OF 26.06.2003

01 - 4

Fig.2.1

01

CHARACTERISTICS

Vehicle identification

MANUFACTURER’S PLATE DISPOSAL TYPE SELF-ADHESIVE

STARTING WITH THE DATE OF 26.06.2003
