6E1–26 X22SE 2.2L ENGINE DRIVEABILITY AND EMISSION Undercarriage Component Locator Table Name Location Fuel Pump Assembly Installed in the top of the fuel tank EVAP Canister Behind rear axle, near fuel tank filler nozzle EVAP Canister Purge Valve Solenoid Behind rear axle, near fuel tank filler nozzle Vehicle Speed Sensor (VSS) Protrudes from the right side of the transmission housing, near the Crankshaft Position (CKP) Sensor Lower left hand front of engine, behind power steering pump bracket Fuse And Relay Panel (Underhood Electrical Center) Underhood (U/H) Fuse and Relay Panel 060RX096 |
