COLLISION DIAGNOSIS
SR-21
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
M
A
B
SR
N
O
P
Seat (with front side
air bag)
If either the front LH or
front RH side air bag
modules has been de-
ployed:
REPLACE front seat-
back assembly on the
deployed side.
If the front LH or front RH side air bag modules have NOT deployed:
1.
Visually check the seat on the collision side.
2.
Remove the seat on the collision side and check the following for damage and
deformities.
-
Harness, connectors and terminals
-
Frame and recliner (for front and rear seat), and also adjuster and slides (for front
seat)
3.
If no damage is found, reinstall the seat.
4.
If damaged—REPLACE the damaged seat parts using new fasteners. If the front
seat back is damaged, the front seat back assembly must be replaced.
Center inner pillar
1.
Check the center inner pillar on the collision side for damage (dents, cracks, deformation).
2.
If damaged—REPAIR the center inner pillar.
Trim/headlining
1.
Check for visible signs of damage (dents, cracks, deformation) of the interior trim on the collision side.
2.
If damaged—REPLACE the damaged trim parts.
Part
SRS is activated
SRS is NOT activated
