PWC-66

< ON-VEHICLE REPAIR >

FRONT POWER WINDOW SWITCH

FRONT POWER WINDOW SWITCH

Removal and Installation

INFOID:0000000005274664

REMOVAL

1.

Remove the front power window switch finisher (2) from the front
door finisher RH. Refer to

INT-14, "Removal and Installation"

.

: Metal clip
:Pawl

2.

Release the four tabs (A), two on each side, then separate the
front power window switch (1) from the finisher (2).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA1098ZZ

REAR POWER WINDOW SWITCH

PWC-67

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

J

L

M

A

B

PWC

N

O

P

REAR POWER WINDOW SWITCH

Removal and Installation - Rear Door Switch (if equipped)

INFOID:0000000005274665

REMOVAL

1.

Remove the rear power window switch finisher (2) from the rear
door finisher. Refer to

INT-14, "Removal and Installation"

.

: Metal clip
:Pawl

2.

Release the two tabs (A), one on either side, then separate the
rear power window switch (1) from the finisher (2).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA1099ZZ

PWO

PWO-1

ELECTRICAL & POWER CONTROL

C

D

E

F

G

H

I

J

K

L

B

SECTION

PWO

A

O

P

N

CONTENTS

POWER OUTLET

PRECAUTION ...............................................

2

PRECAUTIONS ...................................................

2

Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................

2

COMPONENT DIAGNOSIS  ..........................

3

POWER SOCKET  ..............................................

3

Wiring Diagram - Power Socket -  .............................

3

ON-VEHICLE REPAIR ..................................

6

POWER SOCKET  ..............................................

6

FRONT OR CONSOLE POWER SOCKET ..............

6

PWO-2

< PRECAUTION >

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000005550750

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-

tion ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing
serious injury.

• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the

battery, and wait at least 3 minutes before performing any service.
