RECOMMENDED FLUIDS AND LUBRICANTS

MA-17

< ON-VEHICLE MAINTENANCE >

*1: For further details, refer to

*2: If Genuine NISSAN Matic S ATF is not available, Genuine NISSAN Matic J ATF may also be used. Using automatic transmission
fluid other than NISSAN Matic S ATF or Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic transmission
durability, and may damage the automatic transmission, which is not covered by the NISSAN new vehicle limited warranty.

*3: DEXRON

VI type ATF may also be used.

*4: Available in mainland U.S.A. through your NISSAN dealer.

*5: For further details, see “Air conditioner Specification Label”.

*6: See a NISSAN dealer for service for synthetic oil. “SYNTHETIC OIL ONLY” is embossed on the M226 carrier cover.

*7: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 0

C (32

F).

*8: For further details, refer to

GI-35, "Fuel (Regular Unleaded Gasoline Recommended) QR25DE and VQ40DE"

*9: Using automatic transmission fluid other than Genuine NISSAN Matic D ATF may cause deterioration in driveability and transfer
durability, and may damage the transfer, which is not covered by the NISSAN new vehicle limited warranty.

FOR NORTH AMERICA: ANTI-FREEZE COOLANT MIXTURE RATIO

Description

Capacity (Approximate)

Recommended Fluids/Lubricants

Metric

US measure

Imp measure

Fuel

21-1/8 gal

17-5/8 gal

Unleaded gasoline with an octane rat-
ing of at least 87 AKI (RON 91) *8

Engine oil
Drain and refill

With oil filter
change

5.1

5-3/8 qt

4-1/2 qt

• Engine oil with API Certification Mark

• Viscosity SAE 5W-30

Without oil fil-
ter change

4.8

5-1/8 qt

4-1/4 qt

Dry engine (engine overhaul)

6.3

6-5/8 qt

5-1/2 qt

Cooling system

With reservoir
at MAX level

10.2

10-3/4 qt

9 qt

Genuine NISSAN Long Life Anti-freeze
Coolant or equivalent

Automatic transmission fluid (ATF)

10.3

10-7/8 qt

9-1/8 qt

Genuine NISSAN Matic S ATF *2

Manual transmission
fluid (MTF)
(6 M/T)

2WD

3.98

8-3/8 pt

7 pt

Genuine NISSAN Manual Transmission
Fluid (MTF) HQ Multi 75W-85 or API
GL-4, Viscosity SAE 75W-85

4WD

4.18

8-7/8 pt

7-3/8 pt

Rear final drive oil

C200

1.6

3-3/8 pt

2-7/8 pt

Genuine NISSAN differential oil syn-
thetic 75W-90 or API GL-5 synthetic
gear oil, Viscosity SAE 75W-90 *6

M226

2.01

4-1/4 pt

3 1/2 pt

Genuine NISSAN differential oil syn-
thetic 75W-140 or API GL-5 synthetic
gear oil, Viscosity SAE 75W-140 *6

Transfer fluid

TX15B

2.0

2 1/8 qt

1-3/4 qt

Genuine NISSAN Matic D ATF recom-
mended *9.

Front final drive oil

0.85

1-3/4 pt

1-1/2 pt

Genuine NISSAN Differential Oil Hy-
poid Super GL-5 80W-90 or API GL-5
Viscosity SAE 80W-90 *7

Power steering fluid (PSF)

1.0

2-1/8 pt

1-3/4 pt

Genuine NISSAN PSF or equivalent *3

Brake and clutch fluid

—

Genuine NISSAN Super Heavy Duty
Brake Fluid or equivalent, DOT 3 *4

Brake grease

—

PBC (poly butyl cuprysil)

Brake pad plate grease

—

Molykote AS880N grease

Multi-purpose grease

—

NLGI No. 2 (lithium soap base)

Windshield washer fluid

4.5

1-1/4 gal

1 gal

Genuine NISSAN Windshield Washer
Concentrate Cleaner & Anti-freeze or
equivalent

A/C system refrigerant

0.70

0.05 kg

1.54

0.11 lb

1.54

0.11 lb

HFC-134a (R134a) *5

A/C system oil

180 m

6.1 fl oz

6.3 fl oz

NISSAN A/C System Oil Type R or
equivalent *5

MA-18

< ON-VEHICLE MAINTENANCE >

RECOMMENDED FLUIDS AND LUBRICANTS

The engine cooling system is filled at the factory with a high-quality, long life, year-round, anti-freeze coolant
solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system
additives are not necessary.

CAUTION:

• When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Anti-freeze Cool-

ant or equivalent with the proper mixture ratio of 50% anti-freeze and 50% demineralized water or
distilled water.

• Other types of coolant solutions may damage your cooling system.

For North America: SAE Viscosity Number

INFOID:0000000005602311

NISSAN recommends the use of an energy conserving oil in order to
improve fuel economy. Select only engine oils that meet the Ameri-
can Petroleum Institute (API) certification and International Lubricant
Standardization and Approval Committee (ILSAC) certification and
SAE viscosity standard (2). These oils have the API certification
mark (1) on the front of the container. Oils which do not have the
specified quality label should not be used as they could cause
engine damage.

For Mexico: Fluids and Lubricants

INFOID:0000000005550713

FOR MEXICO: FLUIDS AND LUBRICANTS

For outside temperatures down to:

Anti-freeze coolant mixture ratio

Genuine NISSAN Long Life

Antifreeze coolant

Demineralized water or distilled

water

– 35

– 30

50 %

ALPIA0001ZZ

Description

Capacity (Approximate)

Recommended Fluids/Lubricants

Metric

US measure

Imp measure

Fuel

21 1/8 gal

17 5/8 gal

Unleaded gasoline with an octane rat-
ing of at least 87 AKI (RON 91)

Engine oil
Drain and refill

With oil filter change

5.1

5 3/8 qt

4 1/2 qt

Genuine NISSAN engine oil
API grade SL or SM *1
ILSAC grade GF-2, GF-3 or GF-4 *1
Viscosity SAE 10W-30 *1

Without oil filter
change

4.8

5 1/8 qt

4 1/4 qt

Dry engine (engine overhaul)

6.3

6 5/8 qt

5 1/2 qt

Cooling system
(with reservoir at “MAX” level)

10.2

2 3/4 gal

2 1/4 gal

Genuine NISSAN Engine Coolant or
equivalent *2

Automatic transmission fluid (ATF)

10.3

10 7/8 qt

9 1/8 qt

Genuine NISSAN Matic S ATF *3

Rear final drive oil

2.01

4 1/4 pt

3 1/2 pt

API GL-5 synthetic gear oil, Viscosity
SAE 75W-90 or equivalent *4

RECOMMENDED FLUIDS AND LUBRICANTS

MA-19

< ON-VEHICLE MAINTENANCE >

*1: For further details, refer to

MA-19, "For Mexico: SAE Viscosity Number"

*2: Use Genuine NISSAN Engine Coolant or equivalent its quality, in order to avoid possible aluminium corrosion within the
engine cooling system caused by the use of non-genuine engine coolant.

Note that any repairs for the incidents within the engine cooling system while using non-genuine engine coolant may not be
covered by the warranty even if such incidents occurred during the warranty period.

*3: If Genuine NISSAN Matic S ATF is not available, Genuine NISSAN Matic J ATF may also be used. Using automatic transmission
fluid other than Genuine NISSAN Matic S ATF or Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic
transmission durability, and may damage the automatic transmission, which is not covered by the warranty.

*4: See a NISSAN dealership for service for synthetic oil.

*5: DEXRON

VI type ATF can be used.

*6: For further details, see “Air conditioner specification label”.

*7: Using fluid other than Genuine NISSAN Matic D ATF will cause deterioration in driveability and transfer durability, and may damage
the transfer, which is not covered by the warranty.

For Mexico: SAE Viscosity Number

INFOID:0000000005550714

GASOLINE ENGINE

• 5W-30 is preferable.

If 5W-30 is not available, select the viscosity, from the chart, that is
suitable for the outside temperature range.

Transfer fluid

2.0

2 1/8 qt

1 3/4 qt

Genuine NISSAN Matic D ATF recom-
mended *7

Front final drive oil

0.85

1 3/4 pt

1 1/2 pt

Genuine NISSAN Differential Oil Hy-
poid Super GL-5 80W-90 or API GL-5,
Viscosity SAE 80W-90 *1

Power steering fluid (PSF)

1.0

2 1/8 pt

1 3/4 pt

Genuine NISSAN PSF or equivalent *5

Brake fluid

—

DOT 3

Multi-purpose grease

—

NLGI No. 2 (lithium soap base)

Brake grease

—

PBC (poly butyl cuprysil) grease or
equivalent

A/C system refrigerant

0.70

0.05 kg

1.54

0.11 lb

1.54

0.11 lb

HFC-134a (R134a) *6

A/C system oil

180 m

6.1 fl oz

6.34 fl oz

NISSAN A/C System Oil Type R or
equivalent *6

Description

Capacity (Approximate)

Recommended Fluids/Lubricants

Metric

US measure

Imp measure

JPPIA0003GB

MA-20

< ON-VEHICLE MAINTENANCE >

RECOMMENDED FLUIDS AND LUBRICANTS

DIFFERENTIAL GEAR OIL

• 80W-90 for the front final drive is preferable.

For Mexico: Engine Coolant Mixture Ratio

INFOID:0000000005550715

The engine cooling system is filled at the factory with a high-quality,
year-round and extended life engine coolant. The high quality engine
coolant contains the specific solutions effective for the anti-corrosion
and the anti-freeze function. Therefore, additional cooling system
additives are not necessary.

CAUTION:

• When adding or replacing coolant, be sure to use only Genu-

ine NISSAN Engine Coolant.

The use of other types of engine coolant may damage your
cooling system.
• When checking the engine coolant mixture ratio by the coolant

hydrometer, use the chart below to correct your hydrometer read-
ing (specific gravity) according to coolant temperature.

Mixed coolant specific gravity

Unit: specific gravity

WARNING:

Never remove the radiator cap when the engine is hot. Serious burns could be caused by high pres-
sure fluid escaping from the radiator. Wait until the engine and radiator cool down.

JPPIA0001GB

SMA089D

Engine coolant mixture

ratio

Coolant temperature

C (

15 (59)

25 (77)

35 (95)

45 (113)

30%

1.046 - 1.050

1.042 - 1.046

1.038 - 1.042

1.033 - 1.038

50%

1.076 - 1.080

1.070 - 1.076

1.065 - 1.071

1.059 - 1.065
