FRONT FINAL DRIVE
DLN-209
< DISASSEMBLY AND ASSEMBLY >
[FRONT FINAL DRIVE: R180A]
C
E
F
G
H
I
J
K
L
M
A
B
DLN
N
O
P
13. Insert left and right original side bearing adjusting washers in
place between side bearings and gear carrier using Tool.
14. Install the side bearing caps with the matching marks aligned
and tighten the side bearing cap bolts to the specified torque.
Refer to
DLN-192, "Disassembly and Assembly"
15. Apply multi-purpose grease to the lips and differential gear oil to
the circumference of the new side oil seal. Then drive the new
side oil seal in evenly until it becomes flush with the gear carrier
using Tools.
CAUTION:
• Do not reuse side oil seal.
• Do not incline the new side oil seal when installing.
• Apply multi-purpose grease to the lips and differential
gear oil to the circumference of the new side oil seal.
16. Check and adjust tooth contact, backlash, drive gear runout and total preload torque. Refer to
.
Recheck above items.
17. Apply a 3 mm (0.12 in) bead of sealant to the mating surface of
the carrier cover as shown.
• Use Genuine Silicone RTV or equivalent. Refer to
"Recommended Chemical Products and Sealants"
CAUTION:
Remove any old sealant adhering to the mating surfaces.
Also remove any moisture, oil, or foreign material adhering
to the application and mating surfaces.
18. Install the carrier cover to the gear carrier. Tighten the bolts to
the specified torque. Refer to
Differential side shaft
Tool number
: KV38100600 (J-25267)
PDIA0706E
PDIA0700E
Tool number
A: ST30720000 (J-25405)
B: ST27863000 (
—
)
PDIA0711E
PDIA0712E
