DOOR LOCK FUNCTION DLK-15 < FUNCTION DIAGNOSIS > C D E F G H I J L M A B DLK N O P REMOTE KEYLESS ENTRY : System Description INFOID:0000000005274487 OPERATED PROCEDURE • When the keyfob is operated, the signal from the keyfob is sent and the remote keyless entry receiver receives the signal and sends it to the BCM. The BCM only locks/unlocks the doors if the ID number • Using the keyfob, the transmitter sends radio waves to the remote keyless entry receiver, which then sends the received waves to the BCM. Only if the ID number matches does the BCM lock/unlock the doors. • Unless the key is inserted into the ignition key cylinder or one of the doors is opened within 1 minute after the UNLOCK switch on the keyfob is pressed, all the doors are automatically locked. (Auto lock function) • When a door is locked or unlocked, the vehicle turn signal lamps flash and the horn sounds to verify opera- tion. (Active check function) • When the key is in the ignition key cylinder (when the key switch is ON) and one of the doors is open, the door lock function does not work even when the door lock is operated with the keyfob. • Keyfob ID set up is available. REMOTE CONTROL ENTRY FUNCTIONS • When a button on the keyfob is operated, the signal is sent from the keyfob and received by the remote key- less entry receiver. • The received signal is sent to the BCM and compared with the registered ID number. REMOTE CONTROL ENTRY OPERATION CONDITIONS AUTO LOCK FUNCTION Operation Description • Unless the key is inserted into the ignition key cylinder, one of the doors is opened, or the keyfob is operated within 1 minute after a door lock is unlocked by keyfob operation, all the doors are automatically locked. ACTIVE CHECK FUNCTION Operation Description When a door is locked or unlocked by keyfob operation, the vehicle turn signals flash and the horn sounds to keyless remote entry receiver. • The received signal is sent to the BCM and compared with the registered ID number. the IPDM E/R. • The IPDM E/R flashes the turn signal lamps and sounds the horn for each keyfob operation. Keyfob operation Operation condition Door lock operation (locking) • With key removed (key switch: OFF) Door lock operation (unlocking) With key removed (key switch: OFF) |
