AV-160

< ECU DIAGNOSIS >

[PREMIUM AUDIO (CREW CAB)]

BLUETOOTH CONTROL UNIT

BLUETOOTH CONTROL UNIT

Reference Value

INFOID:0000000005274971

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA1805ZZ

Terminal

(wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

output

1

 (R/B)

Ground

Battery power

Input

–

–

Battery voltage

2

(G/Y)

Ground

ACC power

Input

Ignition

switch

ACC/ON

–

Battery  voltage

3

(W/G)

Ground

 IGN power

Input

Ignition

switch

ON/

START

–

Battery  voltage

4

(B)

Ground

Ground

–

–

–

0V

5

–

Shield

–

–

–

–

6

–

Shield

–

–

–

–

7

 (G)

8

(L)

MIC in signal

Input

–

–

–

9

(W)

10

(B)

Audio out

Output

Ignition

switch

ACC/ON

Bluetooth control

unit sends audio

signal

11

(R)

–

Mute control

–

–

–

–

12

(BR)

14

(G)

Steering switch sig-
nal A

Input

Ignition

switch

ON

Pressing



switch

 0V

Pressing

switch

0.75

Pressing VOL up
switch

2V

Except for above

5V

SKIB3609E

AV

BLUETOOTH CONTROL UNIT

AV-161

< ECU DIAGNOSIS >

[PREMIUM AUDIO (CREW CAB)]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

13

(L)

14

(G)

Steering switch sig-
nal B

Input

Ignition

switch

ON

Pressing

switch

0V

Pressing

switch

0.75V

Pressing VOL
down switch

2V

Except for above

5 V

17

(V)

19

(O)

Steering switch sig-
nal A

Output

Ignition

switch

ON

Pressing



switch

 0V

Pressing

switch

0.75

Pressing VOL up
switch

2V

Except for above

5V

18

(LG)

19

(O)

Steering switch sig-
nal B

Output

Ignition

switch

ON

Pressing

switch

0V

Pressing

switch

0.75V

Pressing VOL
down switch

2V

Except for above

5V

20

 (B)

Ground

Ground

–

–

–

0V

21

 (B)

Ground

Ground

–

–

–

0V

22

 (B)

Ground

Ground

–

–

–

0V

28

(SB)

Ground

Vehicle speed sig-
nal (8-pulse)

Input

Ignition

switch

ON

When vehicle

speed is approx. 40

km/h (25 MPH)

29

(Y)

Ground

Microphone power

Output

Ignition

switch

ON

–

5V

33

 (B)

–

Bluetooth antenna

–

–

–

–

34

–

Shield

–

–

–

–

Terminal

(wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

output

PKIA1935E

AV-162

< SYMPTOM DIAGNOSIS >

[PREMIUM AUDIO (CREW CAB)]

AUDIO SYSTEM

SYMPTOM DIAGNOSIS

AUDIO SYSTEM

Symptom Table

INFOID:0000000005274972

AUDIO SYSTEM

CD

SATELLITE RADIO

HANDS-FREE PHONE

Symptom

Possible cause

Reference page

Inoperative

• Audio unit power circuit
• Audio unit

•

AV-108

•

AV-108

Steering wheel audio control switch does not operate

• Steering wheel audio control switch
• Audio unit

•

AV-53

•

AV-108

All speakers do not sound

• Audio unit
• Audio unit power circuit
• Audio amp. ON signal
• Audio amp. power/ground circuit
• Audio amp.

•

AV-108

•

AV-108

•

AV-128

•

AV-109

•

AV-109

One or several speakers do not sound

• Front door speaker
• Front tweeter
• Rear door speaker
• Rear door tweeter
• Subwoofer

•

AV-113

•

AV-116

•

AV-119

•

AV-122

•

AV-125

Symptom

Possible cause

Reference page

CD cannot be inserted.

Audio unit

AV-108

CD cannot be ejected.

The CD cannot be played.

The sound skips, stops suddenly, or is distorted.

Symptom

Possible cause

Reference page

Inoperative

• Satellite radio tuner power or ground circuit
• Satellite radio tuner communication circuit
• Satellite radio tuner

•

AV-108

•

AV-55

•

AV-182

Right or left channel does not sound

• Satellite radio tuner right channel audio signal circuit
• Satellite radio tuner left channel audio signal circuit
• Satellite radio tuner

•

AV-58

Symptom

Possible cause

Reference page

Inoperative

• Bluetooth control unit power circuit
• Bluetooth control unit

•

AV-110

•

AV-107

Steering wheel audio switch does not operate

• Steering wheel audio control switch
• Bluetooth control unit

•

AV-53

•

AV-107

Voice activated control does not activate

• Microphone
• Steering wheel audio control switch
• Bluetooth control unit

•

AV-111

•

AV-53

•

AV-107

AV

NORMAL OPERATING CONDITION

AV-163

< SYMPTOM DIAGNOSIS >

[PREMIUM AUDIO (CREW CAB)]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

NORMAL OPERATING CONDITION

Description

INFOID:0000000005274973

The majority of the audio concerns are the result of outside causes (bad CD, electromagnetic interference,
etc.).

NOISE

The following noise results from variations in field strength, such as fading noise and multi-path noise, or
external noise from trains and other sources. It is not a malfunction.
• Fading noise: This noise occurs because of variations in the field strength in a narrow range due to moun-

tains or buildings blocking the signal.

• Multi-path noise: This noise results from the waves sent directly from the broadcast station arriving at the

antenna at a different time from the waves which reflect off mountains or buildings.

The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning.
Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and opera-
tion of each piece of electrical equipment, and determine the cause.
NOTE:
The source of the noise can be found easily by listening to the noise while removing the fuses of electrical
components, one by one.

Type of Noise and Possible Cause

Occurrence condition

Possible cause

Occurs only when engine is ON.

A continuous growling noise occurs. The speed of
the noise varies with changes in the engine speed.

• Ignition components

The occurrence of the noise is linked with the operation of the fuel pump.

• Fuel pump condenser

Noise only occurs when various
electrical components are oper-
ating.

A cracking or snapping sound occurs with the op-
eration of various switches.

• Relay malfunction, audio unit malfunction

The noise occurs when various motors are operat-
ing.

• Motor case ground
• Motor

The noise occurs constantly, not just under certain conditions.

• Rear defogger coil malfunction
• Open circuit in printed heater
• Poor ground of antenna feeder line

A cracking or snapping sound occurs while the vehicle is being driven, especially when
it is vibrating excessively.

• Ground wire of body parts
• Ground due to improper part installation
• Wiring connections or a short circuit
