MWI-60
< ECU DIAGNOSIS >
COMBINATION METER
22
P
CAN-L
—
—
—
23
B
Ground (Circuit)
—
—
0
24
B/W
Fuel level sensor ground
ON
—
0
25
BR
Generator
ON
Generator voltage low
0
Generator voltage normal
Battery voltage
26
G/R
Parking brake switch
ON
Parking brake applied
0
Parking brake released
Battery voltage
27
V
Brake fluid level switch
ON
Brake fluid level low
0
Brake fluid level normal
Battery voltage
28
L/O
Security indicator input
OFF
Security indicator ON
0
Security indicator OFF
Battery voltage
29
R
Washer fluid level switch
ON
Washer fluid level low
0
Washer fluid level normal
Battery voltage
30
L/B
Vehicle speed signal out-
put (2-pulse)
ON
Speedometer operated
[When vehicle speed is ap-
prox. 20 km/h (12 MPH)]
240 Hz
31
V/W
Vehicle speed signal out-
put (8-pulse)
ON
Speedometer operated
[When vehicle speed is ap-
prox. 40 km/h (25 MPH)]
NOTE:
Maximum voltage may be 12V due to spec-
ifications (connected units).
34
G/B
Fuel level sensor signal
—
—
Refer to
.
35
W/B
Seat belt buckle switch
LH
ON
Unfastened (ON)
0
Fastened (OFF)
Battery voltage
36
L/W
Seat belt buckle switch
RH
ON
Unfastened (ON)
0
Fastened (OFF)
Battery voltage
37
G
Not M range
ON
Manual mode switch OFF
0
Manual mode switch ON
Battery voltage
38
BR
AT shift down
ON
• Manual mode switch ON
• Shift down operation
0
Other than above
Battery voltage
39
W
AT shift up
ON
• Manual mode switch ON
• Shift up operation
0
Other than above
Battery voltage
40
LG/R
M range
ON
Manual mode switch OFF
Battery voltage
Manual mode switch ON
0
Termi-
nal
Wire
color
Item
Condition
Reference value (V)
(Approx.)
Ignition
switch
Operation or condition
PKIC0643E
