ELECTRIC IGNITION SYSTEM EC-1077 < FUNCTION DIAGNOSIS > [VQ35DE] C D E F G H I J K L M A EC N P O 19. Electric throttle control actuator 20. Power valve actuator 2 21. EVAP canister purge volume control solenoid valve 22. Ignition coil (with power transistor) and spark plug (bank 1) 23. Knock sensor 1. Mas air flow sensor (with intake air 2. Air cleaner case 3. Engine coolant temperature sensor 4. EVAP canister purge volume control 5. Power valve actuator 1 6. VIAS control solenoid valve 1 7. VIAS control solenoid valve 2 8. Power valve actuator 2 9. Power steering pressure sensor 10. Tie rod (RH) 11. Power valve actuator 2 12. Camshaft position sensor (PHASE) (bank 1) 13. Camshaft position sensor (PHASE) (bank 2) ALBIA0101ZZ |
