CHG-20

< COMPONENT DIAGNOSIS >

CHARGING SYSTEM

ABMIA0458GB

CHG

CHARGING SYSTEM

CHG-21

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

ABMIA0459GB

CHG-22

< COMPONENT DIAGNOSIS >

CHARGING SYSTEM

ABMIA0460GB

CHG

CHARGING SYSTEM

CHG-23

< SYMPTOM DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

SYMPTOM DIAGNOSIS

CHARGING SYSTEM

Symptom Table

INFOID:0000000004205663

Symptom

Reference

Battery discharged

Refer to

CHG-2, "Work Flow"

.

The charge warning lamp does not illuminate when the ignition
switch is set to ON.

The charge warning lamp does not turn OFF after the engine
starts.

The charging warning lamp turns ON when increasing the engine
speed.
