TM-408 < SYMPTOM DIAGNOSIS > [CVT: RE0F10A] SYSTEM SYMPTOM 24 Other Vehicle runs with CVT in “N” posi- ON vehicle 1. PNP switch 2. CVT fluid level and state 3. CVT position OFF vehicle 4. Gear system 5. Forward clutch 6. Reverse brake 7. Control valve 25 Engine stall. ON vehicle 1. CVT fluid level and state 2. Engine speed signal 3. Primary speed sensor 4. Torque converter clutch solenoid valve 5. CAN communication line 6. Stall test 7. Secondary pressure sensor OFF vehicle 8. Torque converter 9. Control valve 26 Engine stalls when selector lever →“D” or “R”. ON vehicle 1. CVT fluid level and state 2. Engine speed signal 3. Primary speed sensor 4. Torque converter clutch solenoid valve 5. CAN communication line 6. Stall test OFF vehicle 7. Torque converter 8. Control valve 27 Engine speed does not return to idle. ON vehicle 1. CVT fluid level and state 2. Accelerator pedal position sensor 3. Secondary speed sensor 4. CAN communication line OFF vehicle 5. Control valve 28 CVT does not shift ON vehicle 1. CVT fluid level and state 2. CVT position 3. Line pressure test 4. Engine speed signal 5. Accelerator pedal position sensor 6. CAN communication line 7. Primary speed sensor 8. Secondary speed sensor 9. Step motor OFF vehicle 10. Control valve 11. Oil pump assembly 29 Engine does not start in “N” or “P” ON vehicle 1. Ignition switch and starter 2. CVT position 3. PNP switch No. Item Symptom Condition Diagnostic Item Reference |
