SEC-534 < ECU DIAGNOSIS > [SEDAN WITHOUT INTELLIGENT KEY] BCM (BODY CONTROL MODULE) 97 (R/B) Ground Combination switch Input Combination All switch OFF 1.4V Lighting switch flash-to- 1.3V Lighting switch 2ND 1.3V Front wiper switch INT 1.3V Front wiper switch HI 1.3V 98 (G/O) Ground Hazard switch Input Hazard switch Pressed 0 V Not pressed 1.1V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output (+) (-) JPMIA0041GB JPMIA0037GB JPMIA0036GB JPMIA0038GB JPMIA0040GB JPMIA0012GB |
