SIDE WINDOW GLASS
GW-23
< UNIT REMOVAL AND INSTALLATION >
C
D
E
F
G
H
I
J
L
M
A
B
GW
N
O
P
SIDE WINDOW GLASS
Removal
INFOID:0000000009878930
1. Remove the rear door finisher. Refer to
INT-10, "Removal and Installation"
.
2. If the window glass is to be reused, mark the body and the glass with mating marks.
3.
WARNING:
When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help pre-
vent glass splinters from entering your eyes or cutting your hands.
CAUTION:
• When the side window glass is to be reused, do not use a cutting knife or power cutting tool.
• Be careful not to scratch the glass when removing.
• Do not set or stand the glass on its edge. Small chips may develop into cracks.
Remove glass using piano wire or power cutting tool and an
inflatable pump bag.
Installation
INFOID:0000000009878931
Installation is in the reverse order of removal.
• Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur-
nished with it.
• While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out
by passenger compartment air pressure when a door is closed.
• Check gap along bottom to confirm that glass does not contact sheet metal.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNING:
• Keep heat and open flames away as primers and adhesive are flammable.
SBF034B
1.
Side window glass
A.
12.0 mm (0.47 in)
B.
7.0 mm (0.28 in)
AWKIA1733ZZ
