REFRIGERANT HA-19 < BASIC INSPECTION > C D E F G H J K L M A B HA N O P Never look directly into UV lamp light source. drain hose water and illuminating it using UV lamp. • Dust, dirt, and packing materials adhesive used for condenser, evaporator, and other locations may flu- oresce. Be careful not to misidentify leakage. 5. Repair or replace parts where refrigerant leakage occurs and wipe off fluorescent leak detection dye. 6. Use a UV lamp to check that no fluorescent leak detection dye remains after finishing work. WARNING: Never look directly into UV lamp light source. oresce. Be careful not to misidentify leakage. CHECK REFRIGERANT LEAKAGE USING ELECTRICAL LEAK DETECTOR WARNING: Never check refrigerant leakage while the engine is running. CAUTION: Be careful of the following items so that inaccurate checks or misidentifications are avoided. when leakage occurs. 1. Stop the engine. 2. Connect recovery/recycling/recharging equipment or manifold gauge set to A/C service valve. 3. Check that A/C refrigerant pressure is 345 kPa (3.52 kg/cm 2 , 50 psi) or more when temperature is 16 ° C (61 ° F) or more. When pressure is lower than the specified value, recycle refrigerant completely and fill refrigerant to the specified level. 2 , 50 psi) or less when temperature is less than 16 ° C (61 ° F). 4. Clean area where refrigerant leakage check is performed, and check refrigerant leakage along all sur- CAUTION: • Continue checking when a leakage is found. Always continue and complete checking along all pipe connections and A/C system components for additional leakage. • When a leakage is detected, clean leakage area using compressed air and check again. probe surface may not be exposed to water or dirt. NOTE: maximum fan speed while the engine is stopped, and then insert electrical leak detector probe into drain • When disconnecting shut-off valve that is connected to A/C service valve, always evacuate remaining refrigerant so that misidentification can be avoided. 5. Repair or replace parts where refrigerant leakage is detected. (Leakage is detected but leakage area is 6. Start the engine and set A/C control in the following conditions. |
