SECOND SEAT BELT
SB-13
< REMOVAL AND INSTALLATION >
C
D
E
F
G
I
J
K
L
M
A
B
SB
N
O
P
• The webbing can be pulled out when the angle (A) is 15
degrees or less.
• The webbing cannot be pulled out when the angle (B) is 35
degrees or more.
3.
Replace the seat belt assembly if it does not operate normally.
SEAT BELT BUCKLE
SEAT BELT BUCKLE : Removal and Installation
INFOID:0000000009650623
REMOVAL
1.
Remove anchor bolt cap.
2.
Remove seat belt buckle mounting anchor bolt, and then remove seat belt buckle.
INSTALLATION
Install in the reverse order of removal.
SEAT BELT BUCKLE : Inspection
INFOID:0000000009650624
AFTER A COLLISION
WARNING:
Inspect all seat belt assemblies including retractors and attached hardware after any collision.
NISSAN/INFINITI recommends that all seat belt assemblies in use during a collision be replaced
unless the collision was minor and the belts show no damage and continue to operate properly. Fail-
ure to do so could result in serious personal injury in an accident. Seat belt assemblies not in use dur-
ing a collision should also be replaced if either damage or improper operation was noted. Seat belt
pre-tensioners should be replaced even if the seat belts were not in use during a frontal collision in
which the air bags were deployed.
Replace any seat belt assembly (including anchor bolts) if:
• The seat belt is in use at the time of a collision (except for minor collisions and the belts, retractors and buck-
les show no damage and continue to operate properly).
• The seat belt is damaged in an accident. (i.e. torn webbing, bent retractor or guide, etc.)
• The seat belt attaching point is damaged in an accident. Inspect the seat belt attaching area for damage or
distortion and repair if necessary before installing a new seat belt assembly.
• Anchor bolts are deformed or worn out.
• The seat belt pre-tensioner must be replaced even if the seat belts were not in use during the collision in
which the air bags are deployed.
PRELIMINARY CHECKS
1.
Check that the seat belt retractor, seat belt anchor and buckle bolts are tightened firmly.
2.
Repeat step above if necessary to check the other seat belts.
SEAT BELT HOOK
SEAT BELT HOOK : Removal and Installation
INFOID:0000000009650625
REMOVAL
1.
Slide second seat to the frontmost position.
2.
Remove third seat from the vehicle. Refer to
SE-125, "Removal and Installation"
.
3.
Remove luggage side lower finisher. Refer to
INT-43, "LUGGAGE SIDE LOWER FINISHER : Removal
A and B
: Tilting angles
: Vehicle front
JMHIA1064ZZ
