EXL-138 < ECU DIAGNOSIS INFORMATION > BCM (BODY CONTROL MODULE) 19 (BR) Ground Remote keyless en- Input Ignition switch Insert mechanical key into 0 V Remove mechanical key 5 V Remove mechanical key 20 (G/Y) Ground Remote keyless en- Input Ignition switch Insert mechanical key into 0 V Waiting Signal receiving 21 (P/L) Ground NATS antenna amp. Input/ Output Just after inserting ignition key in key cylinder Pointer of tester should move Other than above 0 V 23 (R/Y) Ground Security indicator Input Security indica- ON 0 V Blinking (Ignition switch 11.3 V OFF 12 V 25 (LG) Ground NATS antenna amp. Input/ Output Just after inserting ignition key in key cylinder Pointer of tester should move Other than above 0 V 26 (GR) Ground Thermo control amp. Input Ignition switch ON 0 V Evaporator is extremely low temperature 12 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + − JPMIA0338JP PIIB7728J PIIB7729J JPMIA0014GB |
