Nissan Versa Note. Manual - part 810

TM-120

< WIRING DIAGRAM >

[CVT: RE0F11A]

CVT CONTROL SYSTEM

ABDIA1066GB

CVT SHIFT LOCK SYSTEM

TM-121

< WIRING DIAGRAM >

[CVT: RE0F11A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

CVT SHIFT LOCK SYSTEM

Wiring Diagram

INFOID:0000000009019634

ABDWA0683GB

TM-122

< WIRING DIAGRAM >

[CVT: RE0F11A]

CVT SHIFT LOCK SYSTEM

ABDIA1067GB

CVT SHIFT LOCK SYSTEM

TM-123

< WIRING DIAGRAM >

[CVT: RE0F11A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

ABDIA1068GB
