GW-18

< REMOVAL AND INSTALLATION >

SIDE WINDOW GLASS

• This can be done by applying water to the side window glass area while pushing glass outward.

• To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.

BACK DOOR WINDOW GLASS

GW-19

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

BACK DOOR WINDOW GLASS

Exploded View

INFOID:0000000008969483

Removal and Installation

INFOID:0000000008969484

REMOVAL

1. Remove high-mounted stop lamp. Refer to

EXL-107, "Removal and Installation"

.

2. Remove the back door inner finisher. Refer to

INT-36, "BACK DOOR INNER FINISHER : Removal and

Installation"

.

3. Remove back door window glass using piano wire or power cutting tool (A) and an inflatable pump bag

(B).

• Mark the body and the glass with matching marks if the back door window glass is reused.

• Apply protective tape around the back door window glass to protect the painted surface from damage.

WARNING:

When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help pre-

vent glass splinters from entering your eyes or cutting your hands.

CAUTION:

1.

Back door window glass weatherstrip

2.

Back door window glass locator 3.

Back door window glass spacer

4.

Back door window glass

AWKIA2559ZZ

PIIB5779E

GW-20

< REMOVAL AND INSTALLATION >

BACK DOOR WINDOW GLASS

• Be careful not to scratch the glass when removing.

• Do not set or stand the glass on its edge. Small chips may develop into cracks.

• Apply protective tape around the back door window glass to protect the painted surface from

damage.

INSTALLATION

Installation is in the reverse order of removal.

• Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur-

nished with it.

• Adhesive shall be continuously applied to assure watertightness. Glass installation shall be finished within

five minutes after applying the adhesive.

• While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out

by passenger compartment air pressure when a door is closed.

• The molding must be installed securely so that it is in position and leaves no gap.

• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely

cured (preferably 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.

• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid

contact with the skin and eyes.

• Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled.

If affected by vapor inhalation, immediately move to an area with fresh air.

• Driving the vehicle before the urethane adhesive has completely cured may affect the performance

of the back door window glass in case of an accident.

CAUTION:

• Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six

months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed

on the box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.

• Do not leave primers or adhesive cartridge unattended with their caps open or off.

• The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely

cured. Curing time varies depending on temperature and humidity. The curing time will increase

under lower temperatures and lower humidity.

REPAIRING WATER LEAKS FOR BACK DOOR WINDOW GLASS

• Leaks can be repaired without removing and reinstalling back door window glass.

• If water is leaking between the urethane adhesive material and body or glass, determine the extent of the

leak.

• This can be done by applying water to the back door window glass area while pushing glass outward.

• To stop the leak, apply primer (if necessary) and urethane adhesive to the leak point.

FRONT DOOR GLASS AND REGULATOR

GW-21

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

FRONT DOOR GLASS AND REGULATOR

Exploded View

INFOID:0000000008969486

Removal and Installation

INFOID:0000000009429678

WARNING:

• Before servicing, turn the ignition switch off, disconnect both battery terminals and wait at least

three minutes.

• Do not use air tools or electric tools for servicing.

FRONT DOOR GLASS

Removal

1. Disconnect the battery positive and negative terminals then wait at least three minutes. Refer to

PG-67,

"Removal and Installation (Battery)"

.

2. Remove front door finisher. Refer to

INT-15, "Removal and Installation"

.

3. Remove the vapor barrier. Refer to

GW-21, "Exploded View"

.

CAUTION:

Use care not to damage or tear vapor barrier during removal.

4. Disconnect the harness connector from the door mirror.
5. Temporarily reconnect both battery terminals and the main power window and door lock/unlock switch (LH

door) or power window and door lock/unlock switch (RH door) to raise/lower the front door glass until the

bolts can be seen through the access holes (with power window).

6. Temporarily reinstall the front door glass handle and raise/lower the front door glass until the bolts can be

seen through the access holes (without power window).

1.

Front door panel

2.

Vapor barrier

3.

Front door glass front run

4.

Front door glass rear run

5.

Front door glass

6.

Front door glass rubber run

7.

Front door regulator

8.

Front power window motor

9.

Front door glass handle grommet

10. Front door glass handle

A.

With power window

B.

Without power window

AWKIA2561ZZ
