BCS

BCM

BCS-105

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

34

2

(W)

Ground Output 3 signal

Output

Combination
switch

OFF

7.0 - 8.0 V

HI BEAM

1.2 V

HEADLAMP 2

RR WASHER

35

1

(GR)

Ground Output 2 signal

Output

Combination
switch

OFF

7.0 - 8.0 V

FR WIPER HI

1.2 V

FR WIPER INT
(any intermittent position)

PASSING

HEADLAMP 1

35

2

(GR)

Ground Output 2 signal

Output

Combination
switch

OFF

7.0 - 8.0 V

FR WIPER HI

1.2 V

FR WIPER INT

PASSING

HEADLAMP 1

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

BCS-106

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

BCM

36

(LG)

Ground Output 1 signal

Output

Combination
switch

OFF

7.0 - 8.0 V

FR WASHER

1.2 V

FR WIPER LOW

TURN LH

TURN RH

37

(Y)

Ground Key sw signal

Input

Ignition switch

Ignition key inserted into
ignition key cylinder

Battery voltage

Ignition key removed from
ignition key cylinder

0 V

38

(O)

Ground Ign sw signal

Input

Ignition switch

OFF or ACC

0 V

ON or START

Battery voltage

39

(L)

Ground CAN-H signal

Input/

Output

—

—

40

(P)

Ground CAN-L signal

Input/

Output

—

—

41

(G)

Ground

Door unlock output
(DR) signal

Output

Front door lock
actuator LH

Actuated to UNLOCK po-
sition

Battery voltage

Other than actuated to
UNLOCK position

0 V

42

(Y)

Ground Battery (FUSE)

Input

Ignition switch OFF

Battery voltage

43

(W)

Ground

Battery saver output
signal

Output

Interior room lamp battery saver activated

0 V

Interior room lamp battery saver not activat-
ed

Battery voltage

44

(GR)

Ground

Rear defogger relay
output signal

Input

Rear window
defogger switch

OFF

Battery voltage

ON

0 – 0.5 V

45

(R)

Ground

Room lamp output
signal

Output

Interior room
lamp or map
lamp

OFF

Battery voltage

ON

Battery voltage

DOOR

0 – 1 V

48

(L)

Ground A/C indicator

Input

—

—

50

(G)

Ground Battery (F/L)

Input

Ignition switch OFF

Battery voltage

52

(L)

Ground

Power window pow-
er supply (RAP) sig-
nal

Output

Ignition switch ON

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIB4958J

BCS

BCM

BCS-107

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

53

(G)

Ground

Door unlock output
(AS, RR, RL) signal

Output

Front door lock
actuator RH,
rear door lock
actuator RH and
rear door lock
actuator LH

Actuated to UNLOCK po-
sition

Battery voltage

Other than actuated to
UNLOCK position

0 V

54

(SB)

Ground

Door lock output sig-
nal

Output

All door lock ac-
tuators

Actuated to LOCK posi-
tion

Battery voltage

Other than actuated to
LOCK position

0 V

55

(B)

Ground Gnd

Output

Ignition switch ON

0 V

56

(LG)

Ground Rear wiper output

Output

Rear wiper

OFF (stopped)

0V

ON (activated)

Battery voltage

57

(LG)

Ground Door sw (RR) signal

Input

Rear door
switch RH

OFF (rear door RH
closed)

7.0 - 8.0 V

ON (rear door RH open)

0 V

58

(W)

Ground Door sw (RL) signal

Input

Rear door
switch LH

OFF (rear door LH closed)

7.0 - 8.0 V

ON (rear door LH open)

0 V

59

(SB)

Ground Door sw (DR) signal

Input

Front door
switch LH

OFF (front door LH
closed)

7.0 - 8.0 V

ON (front door LH open)

0 V

60

(O)

Ground Door sw (AS) signal

Input

Front door
switch RH

OFF (front door RH
closed)

7.0 - 8.0 V

ON (front door RH open)

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIB4960J

PKIB4960J

PKIB4960J

BCS-108

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

BCM

1

: With variable intermittent wipers

2

: Without variable intermittent wipers

Fail-safe

INFOID:0000000009693640

FAIL-SAFE CONTROL BY DTC

BCM performs fail-safe control when any DTC are detected.

62

(P)

Ground

Door switch (Back)
signal

Input

Back door
switch

OFF (back door closed)

7.0 - 8.0 V

ON (back door open)

0 V

63

(W)

Ground

Flasher output
(RIGHT) signal

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch RH

6.5 V

(Turn signal lamp turn on: 9 - 16

V)

64

(V)

Ground

Flasher output
(LEFT) signal

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch LH

6.5 V

(Turn signal lamp turn on: 9 - 16

V)

68

(R)

Ground

Rear wiper autostop
switch

Input

Push-button ig-
nition switch ON

Rear wiper stop position

Battery voltage

Any position other than
rear wiper stop position

0V

70

(L)

Ground

Cargo lamp output
signal

Output

Back door

Closed (cargo lamp OFF)

Battery voltage

Open (cargo lamp ON)

0 – 1 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIC6370E

PKIC6370E

Display contents of CONSULT

Fail-safe

Cancellation

B2190: NATS ANTENNA AMP

Inhibit engine cranking

Erase DTC

B2191: DIFFERENCE OF KEY

Inhibit engine cranking

Erase DTC

B2192: ID DISCORD BCM-ECM

Inhibit engine cranking

Erase DTC

B2193: CHAIN OF BCM-ECM

Inhibit engine cranking

Erase DTC
