Nissan Versa Note. Manual - part 75

BCS

BCM

BCS-37

< ECU DIAGNOSIS INFORMATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

32

(P)

Ground OUTPUT 5

Output

Combination
switch

OFF

7.0 - 8.0 V

FR FOG

1.0 V

RR WIPER ON

Wiper intermittent dial 1

Wiper intermittent dial 2

Wiper intermittent dial 6

Wiper intermittent dial 7

33

(V)

Ground OUTPUT 4

Output

Combination
switch

OFF

7.0 - 8.0 V

TAIL LAMP

1.2 V

Wiper intermittent dial 1

Wiper intermittent dial 5

Wiper intermittent dial 6

RR WIPER INT

34

(W)

Ground OUTPUT 3

Output

Combination
switch

OFF

7.0 - 8.0 V

HI BEAM

1.2 V

HEADLAMP 2

RR WASHER

Wiper intermittent dial 1

Wiper intermittent dial 2

Wiper intermittent dial 3

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIB4956J

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

BCS-38

< ECU DIAGNOSIS INFORMATION >

[WITH INTELLIGENT KEY SYSTEM]

BCM

35

(GR)

Ground OUTPUT 2

Output

Combination
switch

OFF

7.0 - 8.0 V

HEADLAMP 1

1.2 V

PASSING

FR WIPER HI

FR WIPER INT
(any intermittent position)

36

(LG)

Ground OUTPUT 1

Output

Combination
switch

OFF

7.0 - 8.0 V

TURN RH

1.2 V

TURN LH

FR WIPER LO

FR WASHER

37

1

(R)

Ground

Park position switch
signal

Input

Selector lever

P (Park) position

0 – 1.5 V

Any position other than P
(Park)

Battery voltage

37

2

(GR)

Ground

Clutch pedal posi-
tion switch signal

Input

Clutch pedal

Depressed

0 – 1.5 V

Released

Battery voltage

38

(G)

Ground

Keyless intelligent
tuner signal

Input

Push-button ig-
nition switch

OFF or ACC

0 – 0.5 V

ON

Battery voltage

39

(L)

Ground CAN-H

Input/

Output

—

—

40

(P)

Ground CAN-L

Input/

Output

—

—

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

BCS

BCM

BCS-39

< ECU DIAGNOSIS INFORMATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

43

(P)

Ground

Door switch (Back)
signal

Input

Back door
switch

OFF (back door closed)

7.0 - 8.0 V

ON (back door open)

0 V

44

(LG)

Ground

Rear wiper autostop
switch

Input

Push-button ig-
nition switch ON

Rear wiper stop position

Battery voltage

Any position other than
rear wiper stop position

0V

45

(O)

Ground

Door switch (AS)
signal

Input

Front door
switch RH

OFF (front RH door
closed)

7.0 - 8.0 V

ON (front RH door open)

0 V

46

(BR)

Ground

Door switch (RR)
signal

Input

Rear door
switch RH

OFF (rear RH door
closed)

7.0 - 8.0 V

ON (rear RH door open)

0 V

47

(SB)

Ground

Door switch (DR)
signal

Input

Front door
switch LH

OFF (front LH door
closed)

7.0 - 8.0 V

ON (front LH door open)

0 V

48

(W)

Ground

Door switch (RL)
signal

Input

Rear door
switch LH

OFF (rear LH door closed)

7.0 - 8.0 V

ON (rear LH door open)

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIB4960J

PKIB4960J

PKIB4960J

PKIB4960J

BCS-40

< ECU DIAGNOSIS INFORMATION >

[WITH INTELLIGENT KEY SYSTEM]

BCM

49

(L)

Ground Cargo lamp control

Output

Back door is closed (cargo lamp turns OFF)

Battery voltage

Back door is opened (cargo lamp turns ON)

0 – 1 V

50

(G)

Ground

Door unlock output
(back)

Output

Back door

UNLOCK (Actuator is acti-
vated)

Battery voltage

Actuator is not activated

0 V

51

(W)

Ground

Request sw (back
door) signal

Input

Back door re-
quest switch

ON (Pressed)

0 – 1.5 V

OFF (Not pressed)

Battery voltage

54

(R)

Ground Rear wiper output

Output

Rear wiper

OFF (stopped)

0V

ON (activated)

Battery voltage

55

(G)

Ground

Door unlock output
(RR, RL)

Output

Rear doors

UNLOCK (Actuator is acti-
vated)

Battery voltage

Actuator is not activated

0 V

56

(W)

Ground Battery saver output

Output

Interior room lamp battery saver timed out

0 V

Except when interior room lamp battery sav-
er timed out

Battery voltage

57

(Y)

Ground

Battery power sup-
ply

Input

Push-button ignition switch OFF

Battery voltage

59

(G)

Ground

Door unlock output
(AS)

Output

Front RH door

UNLOCK (Actuator is acti-
vated)

Battery voltage

Actuator is not activated

0 V

60

(V)

Ground

Flasher output
(LEFT)

Output

Push-button ig-
nition switch ON

Turn signal switch OFF

0 V

Turn signal switch LH

6.5 V

61

(W)

Ground

Flasher output
(RIGHT)

Output

Push-button ig-
nition switch ON

Turn signal switch OFF

0 V

Turn signal switch RH

6.5 V

63

(R)

Ground Room lamp control

Output

Interior room
lamp

OFF

Battery voltage

ON

0 – 1.0 V

65

(SB)

Ground Door lock output

Output

All doors

LOCK (Actuator is activat-
ed)

Battery voltage

Actuator is not activated

0 V

66

(G)

Ground

Door unlock output
(DR)

Output

Front LH door

UNLOCK (Actuator is acti-
vated)

Battery voltage

Actuator is not activated

0 V

67

(B)

Ground Ground

Output

Push-button ignition switch ON

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIC6370E

PKIC6370E
