TM-290 < SYSTEM DESCRIPTION > [CVT: RE0F11A] ON BOARD DIAGNOSTIC (OBD) SYSTEM ON BOARD DIAGNOSTIC (OBD) SYSTEM Description INFOID:0000000009268095 This is an on board diagnosis system which records diagnosis information related to the exhaust gases. It detects malfunctions related to sensors and actuators. The malfunctions are indicated by means of the mal- function indicator lamp (MIL) and are stored as DTC in the ECU memory. The diagnosis information can be checked using a diagnosis tool (GST: Generic Scan Tool). Function of OBD INFOID:0000000009268096 The GST is connected to the diagnosis connector on the vehicle and communicates with the on-board control units to perform diagnosis. The diagnosis connector is the same as for CONSULT. Refer to . |
