C1145, C1146 YAW RATE/SIDE/DECEL G SENSOR BRC-81 < DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS] C D E G H I J K L M A B BRC N O P C1145, C1146 YAW RATE/SIDE/DECEL G SENSOR DTC Logic INFOID:0000000009267640 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1. CHECK SELF DIAGNOSTIC RESULT With CONSULT. 1. Turn ignition switch OFF to ON. 2. Perform self diagnostic result. YES >> Proceed to diagnosis procedure. Refer to . NO >> Inspection End. Diagnosis Procedure INFOID:0000000009267641 1. REPLACE ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Replace ABS actuator and electric unit (control unit). >> Replace ABS actuator and electric unit (control unit). Refer to BRC-108, "Removal and Installa- . DTC Display Item Malfunction detected condition Possible causes C1145 YAW RATE SENSOR • When a malfunction is detected in yaw rate signal. for 2 seconds or more. • When side G signal is not continuously received for 2 seconds or more. • When decel G signal is not continuously received for 2 seconds or more. • Harness or connector (control unit) • Ignition power supply system C1146 SIDE G-SEN CIRCUIT When a malfunction is detected in side/decel G sig- |
