AV-40 < SYSTEM DESCRIPTION > [MID AUDIO] DIAGNOSIS SYSTEM (AUDIO UNIT) 3. While pressing the preset 6 button, turn the volume control dial clockwise or counterclockwise 30 clicks or more. 4. Initially, the communication diagnosis mode is displayed. 5. To exit communication diagnosis, turn the ignition OFF. SELF DIAGNOSIS MODE Hardware/Software Versions 1. Press the DISP button to enter versions display, and the audio head unit software version is displayed. 2. With each additional press of the DISP button, the following information is available: - HARD V###### (hardware version) - EEP V###### (EEPROM version) - @@@@ EQ1-4 # (EQ pin info) If an EQ error is present, INVALID EQ is displayed 3. Hold the DISP button down to return to all display segments screen. Speaker Channel Check ALNIA1516ZZ ALNIA1387GB ALNIA1383GB |
