LAN-8 < SYSTEM DESCRIPTION > [CAN FUNDAMENTAL] TROUBLE DIAGNOSIS Example: TCM branch line open circuit Example: Data link connector branch line open circuit SKIB8738E Unit name Symptom ECM Engine torque limiting is affected, and shift harshness increases. BCM Reverse warning chime does not sound. EPS control unit Normal operation. Combination meter • Shift position indicator and OD OFF indicator turn OFF. ABS actuator and electric unit (control unit) Normal operation. TCM No impact on operation. IPDM E/R Normal operation. SKIB8739E |
