MT-62 [RS6F51R] SERVICE DATA AND SPECIFICATIONS (SDS) Available C-rings ECS00966 MAINSHAFT C-RING *: Always check with the Parts Department for the latest parts information. Available Thrust Washer ECS00967 INPUT SHAFT THRUST WASHER *: Always check with the Parts Department for the latest parts information. DIFFERENTIAL SIDE GEAR THRUST WASHER *: Always check with the Parts Department for the latest parts information. End play 0 - 0.06 mm (0 - 0.0024 in) Thickness mm (in) Part number* Thickness mm (in) Part number* 2.535 (0.0998) 2.805 (0.1104) 32348 8H800 2.835 (0.1116) 2.865 (0.1128) 32348 8H810 Standard length “C2” 154.7 - 154.8 mm (6.091 - 6.094 in) Thickness mm (in) Part number* Thickness mm (in) Part number* 3.84 (0.1512) 32347 8H500 4.02 (0.1583) 32347 8H503 SCIA1008E Allowable clearance between side gear and differential case with washer 0.1 - 0.2 mm (0.004 - 0.008 in) Thickness mm (in) Part number* 0.75 (0.0295) 38424 81X00 |
