EC-310 [QG (WITH EURO-OBD)] DTC P0221 TP SENSOR DTC P0221 TP SENSOR PFP:16119 Component Description EBS00QM3 Electric Throttle Control Actuator consists of throttle control motor, CONSULT-II Reference Value in Data Monitor Mode EBS00QM4 Specification data are reference values. *: Throttle position sensor 2 signal is converted by ECM internally. Thus, it differs from ECM terminal voltage signal. On Board Diagnosis Logic EBS00QM5 This self-diagnosis has the one trip detection logic. FAIL-SAFE MODE When the malfunction is detected, the ECM enters fail-safe mode and the MI lights up. DTC Confirmation Procedure EBS00QM6 NOTE: PBIB0145E MONITOR ITEM CONDITION SPECIFICATION THRTL SEN1 THRTL SEN2 * ● Ignition switch: ON Accelerator pedal: Fully released More than 0.36V ● Shift lever: Accelerator pedal: Fully depressed Less than 4.75V DTC No. Trouble diagnosis name DTC detecting condition Possible cause P0221 Throttle position sensor Rationally incorrect voltage is sent to ECM ● Harness or connector ● Electric throttle control actuator Engine operation condition in fail-safe mode The ECM controls the electric throttle control actuator in regulating the throttle opening in order for the idle position to be within +10 |
