STR-18 < ON-VEHICLE REPAIR > STARTER MOTOR 1. Inspect pinion teeth. dition of ring gear teeth.) 2. Inspect reduction gear teeth. check condition of armature shaft gear teeth.) 3. Check to see if pinion locks in one direction and rotates tions or unusual resistance is evident. BRUSH HOLDER ASSEMBLY Brush • Check wear of brush. • Replace brush if the measurement value is less than the specified value. Brush Spring • Check brush spring tension with brush spring detached from brush. • Replace brush spring if the measurement value is less than the specified value. Brush Holder 1. Perform insulation test between brush holder (positive side) and - Replace brush holder assembly if continuity does not exist. 2. Check brush to see if it moves smoothly. - If brush holder is bent, replace it if sliding surface is dirty, clean. YOKE CHECK SEL630BA Minimum length of brush : Refer to SDS SEL014Z Spring tension (with new SEL015Z SKIB0460E |
