BCM (BODY CONTROL MODULE) INL-69 < ECU DIAGNOSIS INFORMATION > C D E F G H I J K M A B INL N O P 92 (R) Ground Key slot illumination Output Key slot illumina- OFF 0 V Blinking 6.5 V ON Battery voltage 93 (P) Ground ON indicator lamp Output Ignition switch OFF (LOCK and ACC indi- Battery voltage ON 0 V 95 (L) Ground ACC relay control Output Ignition switch OFF 0 V ACC or ON Battery voltage 96 (Y) Ground CVT shift selector Output — Battery voltage 97* 1 (O) Ground Steering lock condi- Input Steering lock LOCK status 0 V UNLOCK status Battery voltage 98* 1 (L) Ground Steering lock condi- Input Steering lock LOCK status Battery voltage UNLOCK status 0 V 99 (V) Ground Selector lever P posi- Input Selector lever P position 0 V Any position other than P Battery voltage 100 (P) Ground Passenger door re- Input Passenger door ON (Pressed) 0 V OFF (Not pressed) 1.0 V 101 Ground Driver door request Input Driver door re- ON (Pressed) 0 V OFF (Not pressed) 1.0 V 102 (Y) Ground Blower fan motor re- Output Ignition switch OFF or ACC 0 V ON Battery voltage 103 (L) Ground Remote keyless entry Output Ignition switch OFF Battery voltage Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JPMIA0015GB JPMIA0016GB JPMIA0016GB |
