BCM (BODY CONTROL MODULE) EXL-307 < ECU DIAGNOSIS INFORMATION > [HALOGEN TYPE] C D E F G H I J K M A B EXL N O P 108 (P) Ground Combination switch Input Combination All switches OFF 1.4 V Lighting switch AUTO 1.3 V Lighting switch 1ST 1.3 V Rear wiper switch INT 1.3 V Any of the conditions below 1.3 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JPMIA0041GB JPMIA0038GB JPMIA0036GB JPMIA0040GB JPMIA0039GB |
